| Número de pieza | TV080X0M-NS0 |
| Marca | BOE |
| Tamaño | 8.0 |
| Solicitud | PAD |
| Resolución | 768×1024 |
| Composición | LCM |
| Brillo | 450 |
| CR | 900:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | WLED |
| Interfaz | MIPI |
| marca de paneles | BOE |
| modelo de panel | TV080X0M-NS0 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 8.0 inch |
| resolución | 768(RGB)×1024 , XGA |
| modo de visualización | ADS, Normally Black, Transmissive |
| área activa | 121.882×162.509 mm |
| describir | 128.142×173.739 mm |
| superficie | |
| brillo | 450 cd/m² (Typ.) |
| relación de contraste | 900:1 (Typ.) |
| mostrar colores | 16.7M (8-bit), CIE193171% |
| tiempo de respuesta | 30 (Typ.)(Tr+Td) |
| ángulo de visión | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 8S3PWLEDWithout Driver |
| interfaz de señal | MIPI (4 data lanes), 34 pins |
| voltaje de entrada | 1.8/5.4/-5.4V (Typ.)(Vio/Vsn/Vsp) |
| solicitud | PAD |
