| Número de pieza | LTL106HL01-001 |
| Marca | Samsung |
| Tamaño | 10.6 |
| Solicitud | PAD |
| Resolución | 1920×1080 |
| Composición | LCM |
| Brillo | 400 |
| CR | 800:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | SAMSUNG |
| modelo de panel | LTL106HL01-001 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 10.6 inch |
| resolución | 1920(RGB)×1080 , FHD |
| modo de visualización | PLS, Normally Black, Transmissive |
| área activa | 234.72×132.03 mm |
| describir | 246.52×149.02×5.2 mm |
| superficie | Glare (Haze 0%), Hard coating (2H) |
| brillo | 400 cd/m² (Typ.) |
| relación de contraste | 800:1 (Typ.) |
| mostrar colores | 16.7M (8-bit), CIE193150% |
| tiempo de respuesta | 16 (Typ.)(Tr+Td) |
| ángulo de visión | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 9S4PWLEDEmbedded (LED Driver) |
| interfaz de señal | LVDS (2 ch, 8-bit), 51 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | PAD |
