| Número de pieza | WEA012864DWPP3N00001 |
| Marca | Winstar |
| Tamaño | 0.96 |
| Solicitud | Instruments & Me |
| Resolución | 128×64 |
| Composición | PM-OLED, OLED |
| Brillo | |
| CR | |
| Colores | Mono(White) |
| Iluminar desde el fondo | self |
| Interfaz | 4-wire |
| marca | Winstar |
| modelo | WEA012864DWPP3N00001 |
| tamaño diagonal | 0.96 inch |
| tipo | PM-OLED, OLED |
| formato de píxel | 128×64 149PPI |
| configuración | Rectangle |
| área activa | 21.74(H)×10.86(V) mm |
| contorno tenue | 38(H)×28.5(V) ×4.37(D) mm |
| área del bisel | 23.94(H)×12.06(V) mm |
| tratamiento | - |
| ver dirección | Symmetry |
| tiempo de respuesta | - |
| ángulo de visión | - |
| modo operativo | - |
| color de soporte | Mono(White) |
| fuente de luz | self |
| peso | - |
| diseñado para | Instruments & Meters |
| cuadros por segundo | - |
| panel táctil | Without |
| detalle d-ic | COG Built-in SSD1306BZ |
| Tipo de interfaz | 4-wire SPI, I²C , 8 pins PIN |
| fuente de alimentación | 3.3/5.0/7.5V (Typ.) |
| ambiente | Operating Temperature: -40 ~ 80 °C ; Storage Temperature: -40 ~ 85 °C |
