| Número de pieza | LP140WD2-TLB1 |
| Marca | LG Display |
| Tamaño | 14.0 |
| Solicitud | NBPC |
| Resolución | 1600×900 |
| Composición | LCM |
| Brillo | 250 |
| CR | 350:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | LG Display |
| modelo de panel | LP140WD2-TLB1 4 Compatible model |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 14.0 inch |
| resolución | 1600(RGB)×900 , HD+ |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 309.12×173.88 mm |
| describir | 320.4×204.6×3.6 mm |
| estilo de forma | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| superficie | Antiglare, Hard coating (3H) |
| brillo | 250 cd/m² (Typ.) |
| relación de contraste | 350:1 (Typ.) |
| mostrar colores | 262K (6-bit), CIE193145% |
| tiempo de respuesta | 16 (Typ.)(Tr+Td) |
| ángulo de visión | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDEmbedded (LED Driver) |
| interfaz de señal | LVDS (2 ch, 6-bit), 40 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | NBPC |
| LP140WD1-TLA1 | LG Display | 14.0 | 1600×900 |
| LP140WD2-TLE2 | LG Display | 14.0 | 1600×900 |
| LP140WH1-TLC6 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLA2 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLF1 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLA1 | LG Display | 14.0 | 1366×768 |
| LP140WH4-TLN1 | LG Display | 14.0 | 1366×768 |
| LP140WHU-TPB2 | LG Display | 14.0 | 1366×768 |
| LP140WX1-TL01 | LG Display | 14.0 | 1280×768 |
| LP140WX1-TL02 | LG Display | 14.0 | 1280×768 |
| B140XTN03.4 | AUO | 14.0 | 1366×768 |
| LP133WQ1-SJEV | LG Display | 13.3 | 2560×1600 |
| LQ164D1LA4B | SHARP | 16.4 | 1600×900 |
| LTN154X1-L03 | Samsung | 15.4 | 1280×800 |
| LTN156AT02-B04 | Samsung | 15.6 | 1366×768 |
| M140NWR2 R2 | IVO | 14.0 | 1366×768 |
| N121IB-L04 | Innolux | 12.1 | 1280×800 |
| N140BGE-L41 | Innolux | 14.0 | 1366×768 |
| N141I1-L04 | Innolux | 14.1 | 1280×800 |
| N164HGE-L11 | Innolux | 16.4 | 1920×1080 |
