| Número de pieza | N141I1-L04 |
| Marca | Innolux |
| Tamaño | 14.1 |
| Solicitud | NBPC |
| Resolución | 1280×800 |
| Composición | LCM |
| Brillo | 240 |
| CR | 400:1 |
| Colores | 262K |
| Iluminar desde el fondo | CCFL |
| Interfaz | LVDS |
| marca de paneles | CMO |
| modelo de panel | N141I1-L04 9 Compatible model |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 14.1 inch |
| resolución | 1280(RGB)×800 , WXGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 303.36×189.6 mm |
| describir | 319.5×218×5.5 mm |
| estilo de forma | Wedge (PCBA Bent, Depth ≥5.2mm) |
| superficie | Antiglare (Haze 26%), Hard coating (3H) |
| brillo | 240 cd/m² (Typ.) |
| relación de contraste | 400:1 (Typ.) |
| mostrar colores | 262K (6-bit) |
| tiempo de respuesta | 5/11 (Typ.)(Tr/Td) |
| ángulo de visión | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 1 pcsCCFLEmbedded (Inverter) |
| interfaz de señal | LVDS (1 ch, 6-bit), 30 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | NBPC |
| AA141TC01 | Mitsubishi | 14.1 | 1280×800 |
| LP141WX5-TLA1 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLC1 | LG Display | 14.1 | 1280×800 |
| LP141WX5-TLP3 | LG Display | 14.1 | 1280×800 |
| LTN141BT04-001 | Samsung | 14.1 | 1440×900 |
| LTN141W1-L09-1 | Samsung | 14.1 | 1280×800 |
| N141I1-L04 | Innolux | 14.1 | 1280×800 |
| N141I3-L01 | Innolux | 14.1 | 1280×800 |
| N141I3-L05 | Innolux | 14.1 | 1280×800 |
| N141I6-D11 | Innolux | 14.1 | 1280×800 |
| B133XTN01.5 | AUO | 13.3 | 1366×768 |
| B140RW03 V1 | AUO | 14.0 | 1600×900 |
| B154SW02 V3 | AUO | 15.4 | 1680×1050 |
| B173HW02 V1 | AUO | 17.3 | 1920×1080 |
| HN116WX1-100 | BOE | 11.6 | 1366×768 |
| LP156WH1-TLC2 | LG Display | 15.6 | 1366×768 |
| LTN150PG-L04 | Samsung | 15.0 | 1400×1050 |
| LTN156AT29-L01 | Samsung | 15.6 | 1366×768 |
| LTN160AT02-002 | Samsung | 16.0 | 1366×768 |
| QD14TL01 Rev.04 | QDI | 14.1 | 1280×800 |
