| Número de pieza | HE070IA-04M |
| Marca | Innolux |
| Tamaño | 7.0 |
| Solicitud | PAD |
| Resolución | 800×1280 |
| Composición | CELL |
| Brillo | 0 |
| CR | 800:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | No B/L |
| Interfaz | MIPI |
| marca de paneles | INNOLUX |
| modelo de panel | HE070IA-04M |
| tipo de panel | a-Si TFT-LCD , CELL |
| Tamaño del panel | 7.0 inch |
| resolución | 800(RGB)×1280 , WXGA |
| modo de visualización | IPS, Normally Black, Transmissive |
| área activa | 94.2×150.72 mm |
| describir | 101.5×159.52×0.77 mm |
| superficie | Hard coating |
| profundidad de vidrio | 0.25+0.25 mm |
| transmisividad | 3.6% (Typ.)(with Polarizer) |
| relación de contraste | 800:1 (Typ.) |
| mostrar colores | 16.7M (8-bit), CIE193160% |
| tiempo de respuesta | 15/25 (Typ.)(Tr/Td) |
| ángulo de visión | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| interfaz de señal | MIPI (4 data lanes), 40 pins |
| voltaje de entrada | 3.3/8.8/22.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| solicitud | PAD |
