| Número de pieza | N070ICE-GB2 |
| Marca | Innolux |
| Tamaño | 7.0 |
| Solicitud | PAD |
| Resolución | 800×1280 |
| Composición | LCM |
| Brillo | 450 |
| CR | 1000:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | WLED |
| Interfaz | MIPI |
| marca de paneles | INNOLUX |
| modelo de panel | N070ICE-GB2 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 7.0 inch |
| resolución | 800(RGB)×1280 , WXGA |
| modo de visualización | IPS, Normally Black, Transmissive |
| área activa | 94.2×150.72 mm |
| describir | 103.5×162.15×3.6 mm |
| superficie | Glare (Haze 0%), Hard coating (3H) |
| brillo | 450 cd/m² (Typ.) |
| relación de contraste | 1000:1 (Typ.) |
| mostrar colores | 16.7M (8-bit) |
| tiempo de respuesta | 14/11 (Typ.)(Tr/Td) |
| ángulo de visión | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 6S3PWLEDWithout Driver |
| interfaz de señal | MIPI (4 data lanes), 31 pins |
| voltaje de entrada | 1.8/3.3V (Typ.)(VDDI/VCI) |
| solicitud | PAD |
