| Número de pieza | HSD070PFW3-D00 |
| Marca | HannStar |
| Tamaño | 7.0 |
| Solicitud | MP4 |
| Resolución | 1024×600 |
| Composición | LCM |
| Brillo | 350 |
| CR | 800:1 |
| Colores | 16.2M |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | HannStar |
| modelo de panel | HSD070PFW3-D00 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 7.0 inch |
| resolución | 1024(RGB)×600 , WSVGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 153.6×90 mm |
| describir | 167.25×104.65×3 mm |
| superficie | |
| brillo | 350 cd/m² (Typ.) |
| relación de contraste | 800:1 (Typ.) |
| mostrar colores | 16.2M (6-bit + FRC), CIE193150% |
| tiempo de respuesta | 4/12 (Typ.)(Tr/Td) |
| ángulo de visión | 80/70/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 4S5PWLEDWithout Driver |
| interfaz de señal | LVDS (1 ch, 8-bit), 31 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | MP4 |
