| Número de pieza | RGS24128022YR000 |
| Marca | RiTdisplay |
| Tamaño | 2.4 |
| Solicitud | IA |
| Resolución | 128×22 |
| Composición | OLED |
| Brillo | 100 |
| CR | 2000:1 |
| Colores | Mono(Yellow) |
| Iluminar desde el fondo | self |
| Interfaz | CPU/SPI/I²C |
| marca de paneles | RiTdisplay |
| modelo de panel | RGS24128022YR000 |
| tipo de panel | PM-OLED , OLED |
| Tamaño del panel | 2.4 inch |
| resolución | 128×22 |
| área activa | 58.85×11.85 mm |
| describir | 63.3×20.8×2.25 mm |
| superficie | Antiglare |
| brillo | 100 cd/m² (Typ.) |
| relación de contraste | 2000 : 1 (Min.) |
| mostrar colores | Mono(Yellow) (1-bit) |
| ángulo de visión | 80/80/80/80 (Min.)(L/R/U/D) |
| frecuencia | 105Hz |
| controlador ic | COG Built-in SSD1305 |
| interfaz de señal | 8-bit 6800/8080 parallel, SPI, I²C, 24 pins |
| voltaje de entrada | 12.0V (Typ.) |
| solicitud | IA |
