| Número de pieza | RGS15128128WR000 |
| Marca | RiTdisplay |
| Tamaño | 1.5 |
| Solicitud | SW |
| Resolución | 128×128 |
| Composición | OLED |
| Brillo | 90 |
| CR | 2000:1 |
| Colores | Mono(White) |
| Iluminar desde el fondo | self |
| Interfaz | CPU/SPI/I²C |
| marca de paneles | RiTdisplay |
| modelo de panel | RGS15128128WR000 |
| tipo de panel | PM-OLED , OLED |
| Tamaño del panel | 1.5 inch |
| resolución | 128×128 |
| área activa | 26.86×26.86 mm |
| describir | 33.8×36.5×1.51 mm |
| superficie | Antiglare |
| brillo | 90 cd/m² (Typ.) |
| relación de contraste | 2000 : 1 (Min.) |
| mostrar colores | Mono(White) (1-bit) |
| ángulo de visión | 80/80/80/80 (Min.)(L/R/U/D) |
| frecuencia | 105Hz |
| controlador ic | COG Built-in SSD1327 |
| interfaz de señal | 8-bit 6800/8080 parallel, SPI, I²C, 25 pins |
| voltaje de entrada | 15V (Typ.)(VCC) |
| solicitud | SW |
