| Número de pieza | NL10276AC30-07 |
| Marca | NLT |
| Tamaño | 15.0 |
| Solicitud | DMPC |
| Resolución | 1024×768 |
| Composición | LCM |
| Brillo | 400 |
| CR | 300:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | CCFL |
| Interfaz | TTL |
| marca de paneles | NEC |
| modelo de panel | NL10276AC30-07 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 15.0 inch |
| resolución | 1024(RGB)×768 , XGA |
| modo de visualización | Normally Black, Transmissive |
| área activa | 304.128×228.096 mm |
| describir | 330×256×30 mm |
| superficie | Hard coating (2H) |
| brillo | 400 cd/m² (Typ.) |
| relación de contraste | 300:1 (Typ.) |
| mostrar colores | 16.7M (6-bit + Hi-FRC), CIE193160% |
| tiempo de respuesta | 10/10 (Typ.)(Tr/Td) |
| ángulo de visión | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 8 pcsCCFLEmbedded (Inverter) |
| interfaz de señal | TTL (2 ch, 8-bit), 75 pins |
| voltaje de entrada | 5.0V (Typ.) |
| solicitud | DMPC |
