| Número de pieza | N156HGE-EA2 |
| Marca | Innolux |
| Tamaño | 15.6 |
| Solicitud | NBPC |
| Resolución | 1920×1080 |
| Composición | LCM |
| Brillo | 300 |
| CR | 500:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | eDP |
| marca de paneles | INNOLUX |
| modelo de panel | N156HGE-EA2 12 Compatible model |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 15.6 inch |
| resolución | 1920(RGB)×1080 , FHD |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 344.16×193.59 mm |
| describir | 359.5×223.8×3.2 mm |
| estilo de forma | Slim (PCBA Flat, Depth ≤3.2mm) |
| superficie | Antiglare (Haze 24%), Hard coating (3H) |
| brillo | 300 cd/m² (Typ.) |
| relación de contraste | 500:1 (Typ.) |
| mostrar colores | 262K (6-bit), CIE193160% |
| tiempo de respuesta | 3/8 (Typ.)(Tr/Td) |
| ángulo de visión | 45/45/20/45 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDEmbedded (LED Driver) |
| interfaz de señal | eDP (2 Lanes), 30 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | NBPC |
