| Número de pieza | M236H1-L07 |
| Marca | Innolux |
| Tamaño | 23.6 |
| Solicitud | DMPC |
| Resolución | 1920×1080 |
| Composición | LCM |
| Brillo | 250 |
| CR | 1200:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | CCFL |
| Interfaz | LVDS |
| marca de paneles | CMO |
| modelo de panel | M236H1-L07 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 23.6 inch |
| resolución | 1920(RGB)×1080 , FHD |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 521.28×293.22 mm |
| describir | 544.8×320.5 mm |
| superficie | Antiglare (Haze 25%), Hard coating (3H) |
| brillo | 250 cd/m² (Typ.) |
| relación de contraste | 1200:1 (Typ.) |
| mostrar colores | 16.7M (6-bit + Hi-FRC), CIE193172% |
| tiempo de respuesta | 0.7/2.3 (Typ.)(Tr+Td) |
| ángulo de visión | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 2 pcsCCFLWithout Driver |
| voltaje de entrada | 5.0V (Typ.) |
| solicitud | DMPC |
