| Número de pieza | LTN133AT09-G02 |
| Marca | Samsung |
| Tamaño | 13.3 |
| Solicitud | NBPC |
| Resolución | 1280×800 |
| Composición | LCM |
| Brillo | 275 |
| CR | 700:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | SAMSUNG |
| modelo de panel | LTN133AT09-G02 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 13.3 inch |
| resolución | 1280(RGB)×800 , WXGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 286.08×178.8 mm |
| describir | 297.15×192.15×3.68 mm |
| estilo de forma | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| superficie | Glare (Haze 0%), Hard coating (3H) |
| brillo | 275 cd/m² (Typ.) |
| relación de contraste | 700:1 (Typ.) |
| mostrar colores | 262K (6-bit), CIE193145% |
| tiempo de respuesta | 16 (Typ.)(Tr+Td) |
| ángulo de visión | 70/70/55/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 9S6PWLEDWithout Driver |
| interfaz de señal | LVDS (1 ch, 6-bit), 30 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | NBPC |
