| Número de pieza | LTL101DL03-T01 |
| Marca | Samsung |
| Tamaño | 10.1 |
| Solicitud | PAD |
| Resolución | 2560×1600 |
| Composición | LCM |
| Brillo | 370 |
| CR | 800:1 |
| Colores | 16.2M |
| Iluminar desde el fondo | WLED |
| Interfaz | eDP |
| marca de paneles | SAMSUNG |
| modelo de panel | LTL101DL03-T01 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 10.1 inch |
| resolución | 2560RG(BW)×1600 , WQXGA |
| modo de visualización | PLS, Normally Black, Transmissive |
| área activa | 216.576×135.36 mm |
| describir | 232.22×156.92×5.2 mm |
| superficie | Glare (Haze 0%), Hard coating (2H) |
| brillo | 370 cd/m² (Typ.) |
| relación de contraste | 800:1 (Typ.) |
| mostrar colores | 16.2M (6-bit + FRC) |
| tiempo de respuesta | 16 (Typ.)(Tr+Td) |
| ángulo de visión | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 7S6PWLEDEmbedded (LED Driver) |
| interfaz de señal | eDP (4 Lanes), 45 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | PAD |
