| Número de pieza | LTL089CL02-W02 |
| Marca | Samsung |
| Tamaño | 8.9 |
| Solicitud | PAD |
| Resolución | 1920×1200 |
| Composición | LCM |
| Brillo | 450 |
| CR | 900:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | MIPI |
| marca de paneles | SAMSUNG |
| modelo de panel | LTL089CL02-W02 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 8.9 inch |
| resolución | 1920(RGB)×1200 , WUXGA |
| modo de visualización | PLS, Normally Black, Transmissive |
| área activa | 191.52×119.7 mm |
| describir | 203.5×135.9×5.2 mm |
| superficie | Glare (Haze 0%), Hard coating (2H) |
| brillo | 450 cd/m² (Typ.) |
| relación de contraste | 900:1 (Typ.) |
| mostrar colores | 262K (6-bit) |
| tiempo de respuesta | 16 (Typ.)(Tr+Td) |
| ángulo de visión | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 7S5PWLEDWithout Driver |
| interfaz de señal | MIPI (4 data lanes), 45 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | PAD |
