| Número de pieza | LP101WX2-SLA1 |
| Marca | LG Display |
| Tamaño | 10.1 |
| Solicitud | PAD |
| Resolución | 1280×800 |
| Composición | Assembly |
| Brillo | 360 |
| CR | 500:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | LG Display |
| modelo de panel | LP101WX2-SLA1 |
| tipo de panel | a-Si TFT-LCD , Assembly |
| Tamaño del panel | 10.1 inch |
| resolución | 1280(RGB)×800 , WXGA |
| área activa | 216.96×135.6 mm |
| describir | 257.2×175.4×5.9 mm |
| superficie | Anti Fingerprint |
| brillo | 360 cd/m² (Typ.) |
| relación de contraste | 500:1 (Min.) |
| mostrar colores | 16.7M (6-bit + Hi-FRC) |
| ángulo de visión | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| interfaz de señal | LVDS (1 ch, 8-bit), 40 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | PAD |
