| Número de pieza | LB084S01-TL01 |
| Marca | LG Display |
| Tamaño | 8.4 |
| Solicitud | IA |
| Resolución | 800×600 |
| Composición | LCM |
| Brillo | 600 |
| CR | 600:1 |
| Colores | 262K/16.7M |
| Iluminar desde el fondo | CCFL |
| Interfaz | LVDS |
| marca de paneles | LG.Philips LCD |
| modelo de panel | LB084S01-TL01 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 8.4 inch |
| resolución | 800(RGB)×600 , SVGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 170.4×127.8 mm |
| describir | 189.5×148.6×9.4 mm |
| superficie | Antiglare, Hard coating (3H) |
| brillo | 600 cd/m² (Typ.) |
| relación de contraste | 600:1 (Typ.) |
| mostrar colores | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193145% |
| tiempo de respuesta | 7/18 (Typ.)(Tr/Td) |
| ángulo de visión | 75/75/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 2 pcsCCFLWithout Driver |
| interfaz de señal | LVDS (1 ch, 6/8-bit), 20 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | IA |
