| Número de pieza | HB140WX1-401 |
| Marca | BOE |
| Tamaño | 14.0 |
| Solicitud | NBPC |
| Resolución | 1366×768 |
| Composición | LCM |
| Brillo | 200 |
| CR | 500:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | eDP |
| marca de paneles | BOE |
| modelo de panel | HB140WX1-401 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 14.0 inch |
| resolución | 1366(RGB)×768 , WXGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 309.399×173.952 mm |
| describir | 320.9×187.6×3.6 mm |
| estilo de forma | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| superficie | Antiglare, Hard coating (3H) |
| brillo | 200 cd/m² (Typ.) |
| relación de contraste | 500:1 (Typ.) |
| mostrar colores | 262K (6-bit), CIE193145% |
| tiempo de respuesta | 12 (Typ.)(Tr+Td) |
| ángulo de visión | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 9S4PWLEDEmbedded (LED Driver) |
| interfaz de señal | eDP (1 Lane), 30 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | NBPC |
