| Número de pieza | AM-640480GJTNQW-TA0H |
| Marca | AMPIRE |
| Tamaño | 5.7 |
| Solicitud | IA |
| Resolución | 640×480 |
| Composición | LCM |
| Brillo | 425 |
| CR | 250:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | AMPIRE |
| modelo de panel | AM-640480GJTNQW-TA0H |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 5.7 inch |
| resolución | 640(RGB)×480 , VGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 115.2×86.4 mm |
| describir | 127×98.43×9.84 mm |
| superficie | |
| brillo | 425 cd/m² (Typ.) |
| relación de contraste | 250:1 (Typ.) |
| mostrar colores | 262K (6-bit), CIE193150% |
| tiempo de respuesta | 50 (Typ.)(Tr+Td) |
| ángulo de visión | 70/70/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDEmbedded (LED Driver) |
| interfaz de señal | LVDS (1 ch, 8-bit), 20 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | IA |
| AM-640480G2TNQW-00H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-A0H | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-T01H | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| COM57H5M10XRC | ORTUSTECH | 5.7 | 640×480 |
| EL320.240.36 HB NE CC | PLANAR | 5.7 | 320×240 |
| AA104VC10 | Mitsubishi | 10.4 | 640×480 |
| G121SN01 V1 | AUO | 12.1 | 800×600 |
| LB104S01-TL02 | LG Display | 10.4 | 800×600 |
| LM32019T | SHARP | 5.7 | 320×240 |
| LM80C209 | SHARP | 11.3 | 800×600 |
| NL8060BC21-11C | NLT | 8.4 | 800×600 |
| RGS24128022YR000 | RiTdisplay | 2.4 | 128×22 |
| TX18D41VM0EAA | KOE | 7.0 | 1024×600 |
| UG-2864KLBMG01 | WiseChip | 1.54 | 128×64 |
| UG-6028GDEBF02 | WiseChip | 1.7 | 160×128 |
