| Número de pieza | 28QVF2H |
| Marca | SII |
| Tamaño | 2.8 |
| Solicitud | HHP |
| Resolución | 240×320 |
| Composición | LCM |
| Brillo | 350 |
| CR | 800:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | TTL |
| marca de paneles | SII |
| modelo de panel | 28QVF2H |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 2.8 inch |
| resolución | 240(RGB)×320 , QVGA |
| modo de visualización | FFS, Normally Black, Transmissive |
| área activa | 43.2×57.6 mm |
| describir | 49×69 mm |
| superficie | Clear, Hard coating |
| brillo | 350 cd/m² (Typ.) |
| relación de contraste | 800:1 (Typ.) |
| mostrar colores | 262K (6-bit), CIE193172% |
| tiempo de respuesta | 35 (Typ.)(Tr+Td) |
| ángulo de visión | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lámpara | 4S1PWLED |
| interfaz de señal | Parallel RGB (1 ch, 6-bit) + SPI, 35 pins |
| voltaje de entrada | (1.65~3.3)/(2.5~3.3)(IOVCC/VCI) |
| solicitud | HHP |
