| Número de pieza | TM035NDH04 |
| Marca | Tianma |
| Tamaño | 3.5 |
| Solicitud | HHP |
| Resolución | 272×480 |
| Composición | LCM |
| Brillo | 300 |
| CR | 500:1 |
| Colores | 65K/262K |
| Iluminar desde el fondo | WLED |
| Interfaz | CPU |
| marca de paneles | TIANMA |
| modelo de panel | TM035NDH04 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 3.5 inch |
| resolución | 272(RGB)×480 , WQVGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 43.86×77.4 mm |
| describir | 50.86×87.98×2.5 mm |
| superficie | Antiglare |
| brillo | 300 cd/m² (Typ.) |
| relación de contraste | 500:1 (Typ.) |
| mostrar colores | 65K/262K , CIE193150% |
| tiempo de respuesta | 20 (Typ.)(Tr+Td) |
| ángulo de visión | 60/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lámpara | 1S6PWLEDWithout Driver |
| interfaz de señal | CPU, 41 pins |
| voltaje de entrada | 2.8/2.8V (Typ.)(IOVCC/VCC) |
| solicitud | HHP |
