| Número de pieza | YXD101301000-60 |
| Marca | SEBO |
| Tamaño | 10.1 |
| Solicitud | CNS |
| Resolución | 1024×600 |
| Composición | LCM |
| Brillo | 1000 |
| CR | 600:1 |
| Colores | 16.2M |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | SEBO |
| modelo de panel | YXD101301000-60 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 10.1 inch |
| resolución | 1024(RGB)×600 , WSVGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 222.72×125.28 mm |
| describir | 235×149.2×6.3 mm |
| superficie | Antiglare |
| brillo | 1000 cd/m² (Typ.) |
| relación de contraste | 600:1 (Typ.) |
| mostrar colores | 16.2M (6-bit + FRC), CIE193152% |
| tiempo de respuesta | 25 (Typ.)(Tr+Td) |
| ángulo de visión | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDWithout Driver |
| interfaz de señal | LVDS (1 ch, 8-bit), 60 pins |
| voltaje de entrada | 3.3/9.6/18/-6V (Typ.)(DVDD/AVDD/VGH/VGL) |
| solicitud | CNS |
