| Número de pieza | VVX07F015M00 |
| Marca | Panasonic |
| Tamaño | 7.0 |
| Solicitud | PAD |
| Resolución | 1200×1920 |
| Composición | LCM |
| Brillo | 450 |
| CR | 1200:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | WLED |
| Interfaz | MIPI |
| marca de paneles | Panasonic |
| modelo de panel | VVX07F015M00 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 7.0 inch |
| resolución | 1200(RGB)×1920 , WUXGA |
| modo de visualización | IPS, Normally Black, Transmissive |
| área activa | 94.5×151.2 mm |
| describir | 104.52×161.87×2.4 mm |
| superficie | Hard coating |
| brillo | 450 cd/m² (Typ.) |
| relación de contraste | 1200:1 (Typ.) |
| mostrar colores | 16.7M (8-bit), CIE193172% |
| tiempo de respuesta | 30 (Max.)(Tr+Td) |
| ángulo de visión | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 4S6PWLEDWithout Driver |
| interfaz de señal | MIPI (4 data lanes), 40 pins |
| voltaje de entrada | 1.8/3.7V (Typ.)(VCC/VDD) |
| solicitud | PAD |
