| Número de pieza | V460H1-LS1 |
| Marca | Innolux |
| Tamaño | 46 |
| Solicitud | LCTV |
| Resolución | 1920×1080 |
| Composición | LCM |
| Brillo | 350 |
| CR | 6000:1 |
| Colores | 1.07B |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | CHIMEI INNOLUX |
| modelo de panel | V460H1-LS1 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 46 inch |
| resolución | 1920(RGB)×1080 , FHD |
| modo de visualización | Super MVA, Normally Black, Transmissive |
| área activa | 1018.08×572.67 mm |
| describir | 1076.5×634.7 mm |
| superficie | Antiglare (Haze 11%), Hard coating (3H) |
| brillo | 350 cd/m² (Typ.) |
| relación de contraste | 6000:1 (Typ.) |
| mostrar colores | 1.07B (8-bit + Hi-FRC), CIE193172% |
| tiempo de respuesta | 6 (Typ.)(G to G) |
| ángulo de visión | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frecuencia | 120Hz |
| tipo de lámpara | 4 stringsWLEDEmbedded (LED Driver) |
| interfaz de señal | LVDS (4 ch, 10-bit), 102 pins |
| voltaje de entrada | 12.0V (Typ.) |
| solicitud | LCTV |
