| Número de pieza | V315B3-L04 |
| Marca | Innolux |
| Tamaño | 31.5 |
| Solicitud | LCTV |
| Resolución | 1366×768 |
| Composición | LCM |
| Brillo | 450 |
| CR | 2500:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | CCFL |
| Interfaz | LVDS |
| marca de paneles | CMO |
| modelo de panel | V315B3-L04 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 31.5 inch |
| resolución | 1366(RGB)×768 , WXGA |
| modo de visualización | Super MVA, Normally Black, Transmissive |
| área activa | 697.685×392.256 mm |
| describir | 760×450 mm |
| superficie | |
| brillo | 450 cd/m² (Typ.) |
| relación de contraste | 2500:1 (Typ.) |
| mostrar colores | 16.7M (6-bit + Hi-FRC), CIE193172% |
| tiempo de respuesta | 8.5 (Typ.)(G to G) |
| ángulo de visión | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 6 pcsCCFLEmbedded (Inverter) |
| interfaz de señal | LVDS (1 ch, 8-bit), 30 pins |
| voltaje de entrada | 12.0V (Typ.) |
| solicitud | LCTV |
