| Número de pieza | TX31D32VM2AAA |
| Marca | KOE |
| Tamaño | 12.1 |
| Solicitud | IA |
| Resolución | 800×600 |
| Composición | LCM |
| Brillo | 400 |
| CR | 500:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | CCFL |
| Interfaz | LVDS |
| marca de paneles | HITACHI |
| modelo de panel | TX31D32VM2AAA |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 12.1 inch |
| resolución | 800(RGB)×600 , SVGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 246×184.5 mm |
| describir | 280×210×13.5 mm |
| superficie | Hard coating (3H) |
| brillo | 400 cd/m² (Typ.) |
| relación de contraste | 500:1 (Typ.) |
| mostrar colores | 16.7M (8-bit) |
| tiempo de respuesta | 15/10 (Typ.)(Tr/Td) |
| ángulo de visión | 65/65/55/65 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 2 pcsCCFLWithout Driver |
| interfaz de señal | LVDS (1 ch, 8-bit), 20 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | IA |
