| Número de pieza | TX26D203VM2BAA |
| Marca | KOE |
| Tamaño | 10.4 |
| Solicitud | IA |
| Resolución | 1024×768 |
| Composición | LCM |
| Brillo | 1200 |
| CR | 800:1 |
| Colores | 262K/16.7M |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | KOE |
| modelo de panel | TX26D203VM2BAA |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 10.4 inch |
| resolución | 1024(RGB)×768 , XGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 211.2×158.4 mm |
| describir | 235×180.2×10 mm |
| superficie | |
| brillo | 1200 cd/m² (Typ.) |
| relación de contraste | 800:1 (Typ.) |
| mostrar colores | 262K/16.7M (6-bit / 8-bit), CIE193150% |
| tiempo de respuesta | 16 (Typ.)(Tr+Td) |
| ángulo de visión | 75/75/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 4 stringsWLEDWithout Driver |
| interfaz de señal | LVDS (1 ch, 6/8-bit), 20 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | IA |
