| Número de pieza | SVA190WX05TB |
| Marca | SVA-NEC |
| Tamaño | 19.0 |
| Solicitud | DMPC |
| Resolución | 1440×900 |
| Composición | LCM |
| Brillo | 300 |
| CR | 1000:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | CCFL |
| Interfaz | LVDS |
| marca de paneles | SVA-NEC |
| modelo de panel | SVA190WX05TB |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 19.0 inch |
| resolución | 1440(RGB)×900 , WXGA+ |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 408.24×255.15 mm |
| describir | 428×278 mm |
| superficie | Antiglare, Hard coating (3H) |
| brillo | 300 cd/m² (Typ.) |
| relación de contraste | 1000:1 (Typ.) |
| mostrar colores | 16.7M (6-bit + Hi-FRC), CIE193172% |
| tiempo de respuesta | |
| ángulo de visión | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 4 pcsCCFL |
| interfaz de señal | LVDS (2 ch, 8-bit) |
| rohs: | |
| solicitud | DMPC |
