| Número de pieza | RGS31256032WH000 |
| Marca | RiTdisplay |
| Tamaño | 3.1 |
| Solicitud | IA |
| Resolución | 256×32 |
| Composición | OLED |
| Brillo | 100 |
| CR | 2000:1 |
| Colores | Mono(White) |
| Iluminar desde el fondo | self |
| Interfaz | CPU/SPI/I²C |
| marca de paneles | RiTdisplay |
| modelo de panel | RGS31256032WH000 |
| tipo de panel | PM-OLED , OLED |
| Tamaño del panel | 3.1 inch |
| resolución | 256×32 |
| área activa | 79.084×9.868 mm |
| describir | 83.8×18×1.71 mm |
| superficie | Antiglare |
| brillo | 100 cd/m² (Typ.) |
| relación de contraste | 2000 : 1 (Min.) |
| mostrar colores | Mono(White) (1-bit) |
| ángulo de visión | 80/80/80/80 (Min.)(L/R/U/D) |
| frecuencia | 105Hz |
| controlador ic | COF Built-in SSD1326U3R1 |
| interfaz de señal | 8-bit 6800/8080 parallel, SPI, I²C, 25 pins |
| voltaje de entrada | 12/2.7V (Typ.)(VCC/VDD) |
| solicitud | IA |
