| Número de pieza | NL6448BC20-35D |
| Marca | NLT |
| Tamaño | 6.5 |
| Solicitud | IA |
| Resolución | 640×480 |
| Composición | LCM |
| Brillo | 600 |
| CR | 800:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | TTL |
| marca de paneles | NEC |
| modelo de panel | NL6448BC20-35D |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 6.5 inch |
| resolución | 640(RGB)×480 , VGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 132.48×99.36 mm |
| describir | 153×118 mm |
| superficie | Antiglare, Hard coating (3H) |
| brillo | 600 cd/m² (Typ.) |
| relación de contraste | 800:1 (Typ.) |
| mostrar colores | 262K (6-bit), CIE193140% |
| tiempo de respuesta | 3/15 (Typ.)(Tr/Td) |
| ángulo de visión | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 3 stringsWLEDWithout Driver |
| interfaz de señal | CMOS (1 ch, 6-bit), 31 pins |
| voltaje de entrada | 3.3/5.0V (Typ.) |
| solicitud | IA |
| NL6448BC18-01 | NLT | 5.7 | 640×480 |
| NL6448BC18-06F | NLT | 5.7 | 640×480 |
| NL6448BC20-08E | NLT | 6.5 | 640×480 |
| NL6448BC20-20 | NLT | 6.5 | 640×480 |
| NL6448BC20-30F | NLT | 6.5 | 640×480 |
| NL6448BC26-27 | NLT | 8.4 | 640×480 |
| NL6448BC33-21 | NLT | 10.4 | 640×480 |
| NL6448BC33-63D | NLT | 10.4 | 640×480 |
| NL6448BC33-64E | NLT | 10.4 | 640×480 |
| NL6448BC33-70D | NLT | 10.4 | 640×480 |
| AA050MG01 | Mitsubishi | 5.0 | 800×480 |
| B084SN02 V0 | AUO | 8.4 | 800×600 |
| DMF5005N-EB | Kyocera | 5.2 | 240×64 |
| KCS057QV1AJ-G23 | Kyocera | 5.7 | 320×240 |
| LM081HB1T01 | SHARP | 8.1 | 640×240 |
| LM64C21P | SHARP | 8.0 | 640×480 |
| LQ057Q3DG02 | SHARP | 5.7 | 320×240 |
| LTA057A340F | TOSHIBA | 5.7 | 320×240 |
| MD400F640PD5 | Panasonic | 9.8 | 640×400 |
| TX14D11VM1CAA | KOE | 5.7 | 320×240 |
