| Número de pieza | NL192108AC10-01D |
| Marca | NLT |
| Tamaño | 9.0 |
| Solicitud | IA |
| Resolución | 1920×1080 |
| Composición | LCM |
| Brillo | 400 |
| CR | 700:1 |
| Colores | 262K/16.7M |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | NLT |
| modelo de panel | NL192108AC10-01D |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 9.0 inch |
| resolución | 1920(RGB)×1080 , FHD |
| modo de visualización | UA-SFT, Normally Black, Transmissive |
| área activa | 198.72×111.78 mm |
| describir | 214.6×130×9.6 mm |
| superficie | Antiglare (Haze 41%), Hard coating (2H), Antireflection |
| brillo | 400 cd/m² (Typ.) |
| relación de contraste | 700:1 (Typ.) |
| mostrar colores | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| tiempo de respuesta | 13/12 (Typ.)(Tr/Td) |
| ángulo de visión | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDEmbedded (LED Driver) |
| interfaz de señal | LVDS (2 ch, 6/8-bit), 50 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | IA |
