| Número de pieza | NL160120BC27-14 |
| Marca | NLT |
| Tamaño | 21.3 |
| Solicitud | DMPC |
| Resolución | 1600×1200 |
| Composición | LCM |
| Brillo | 250 |
| CR | 550:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | CCFL |
| Interfaz | LVDS |
| marca de paneles | NEC |
| modelo de panel | NL160120BC27-14 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 21.3 inch |
| resolución | 1600(RGB)×1200 , UXGA |
| modo de visualización | SA-SFT, Normally Black, Transmissive |
| área activa | 432×324 mm |
| describir | 457×350 mm |
| superficie | Antiglare, Hard coating (2H) |
| brillo | 250 cd/m² (Typ.) |
| relación de contraste | 550:1 (Typ.) |
| mostrar colores | 16.7M (8-bit), CIE193172% |
| tiempo de respuesta | 11/9 (Typ.)(Tr/Td) |
| ángulo de visión | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 6 pcsCCFLWithout Driver |
| interfaz de señal | LVDS (2 ch, 8-bit), 40 pins |
| voltaje de entrada | 12.0V (Typ.) |
| solicitud | DMPC |
