| Número de pieza | N154Z1-L01 |
| Marca | Innolux |
| Tamaño | 15.4 |
| Solicitud | NBPC |
| Resolución | 1680×1050 |
| Composición | LCM |
| Brillo | 200 |
| CR | 500:1 |
| Colores | 262K |
| Iluminar desde el fondo | CCFL |
| Interfaz | LVDS |
| marca de paneles | CMO |
| modelo de panel | N154Z1-L01 9 Compatible model |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 15.4 inch |
| resolución | 1680(RGB)×1050 , WSXGA+ |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 331.128×206.955 mm |
| describir | 344×222×6.5 mm |
| estilo de forma | Wedge (PCBA Bent, Depth ≥5.2mm) |
| superficie | Antiglare, Hard coating (2H) |
| brillo | 200 cd/m² (Typ.) |
| relación de contraste | 500:1 (Typ.) |
| mostrar colores | 262K (6-bit), CIE193145% |
| tiempo de respuesta | 4/12 (Typ.)(Tr/Td) |
| ángulo de visión | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 1 pcsCCFLWithout Driver |
| interfaz de señal | LVDS (2 ch, 6-bit), 30 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | NBPC |
| B154EW02 V1 | AUO | 15.4 | 1280×800 |
| LP154WX4-TLC5 | LG Display | 15.4 | 1280×800 |
| LTN154AT07-H01 | Samsung | 15.4 | 1280×800 |
| LTN154AT07-L01 | Samsung | 15.4 | 1280×800 |
| LTN154P1-L03 | Samsung | 15.4 | 1680×1050 |
| N154C6-L04 | Innolux | 15.4 | 1440×900 |
| N154I6-L03 | Innolux | 15.4 | 1280×800 |
| N154Z1-L01 | Innolux | 15.4 | 1680×1050 |
| N154Z1-L02 | Innolux | 15.4 | 1680×1050 |
| N154Z3-L01 | Innolux | 15.4 | 1680×1050 |
| B141XN04 V2 | AUO | 14.1 | 1024×768 |
| LP125WH2-SLB2 | LG Display | 12.5 | 1366×768 |
| LP140WD1-TLM1 | LG Display | 14.0 | 1600×900 |
| LP140WH2-TLB1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TPS1 | LG Display | 14.0 | 1366×768 |
| LP154WU1-A1K3 | LG Display | 15.4 | 1920×1200 |
| LP171WU6-TLA2 | LG Display | 17.1 | 1920×1200 |
| LTD121EXSS | TOSHIBA | 12.1 | 1280×800 |
| LTN141AT16-003 | Samsung | 14.1 | 1280×800 |
| LTN154X3-L03 | Samsung | 15.4 | 1280×800 |
