| Número de pieza | M185XW01 VF |
| Marca | AUO |
| Tamaño | 18.5 |
| Solicitud | DMPC |
| Resolución | 1366×768 |
| Composición | LCM |
| Brillo | 250 |
| CR | 1000:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | AUO |
| modelo de panel | M185XW01 VF |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 18.5 inch |
| resolución | 1366(RGB)×768 , WXGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 409.8×230.4 mm |
| describir | 430.4×254.6×10.4 mm |
| superficie | Antiglare, Hard coating (3H) |
| brillo | 250 cd/m² (Typ.) |
| relación de contraste | 1000:1 (Typ.) |
| mostrar colores | 16.7M (6-bit + Hi-FRC), CIE193172% |
| tiempo de respuesta | 3.6/1.4 (Typ.)(Tr/Td) |
| ángulo de visión | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 10S4PWLEDWithout Driver |
| interfaz de señal | LVDS (1 ch, 8-bit), 30 pins |
| voltaje de entrada | 5.0V (Typ.) |
| solicitud | DMPC |
