| Número de pieza | LTY400WS-L02 |
| Marca | Samsung |
| Tamaño | 40 |
| Solicitud | LCTV |
| Resolución | 1366×768 |
| Composición | LCM |
| Brillo | 530 |
| CR | 1200:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | CCFL |
| Interfaz | LVDS |
| marca de paneles | S-LCD |
| modelo de panel | LTY400WS-L02 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 40 inch |
| resolución | 1366(RGB)×768 , WXGA |
| modo de visualización | S-PVA, Normally Black, Transmissive |
| área activa | 885.168×497.664 mm |
| describir | 952×551×52 mm |
| superficie | Antiglare (Haze 44%), Hard coating (3H) |
| brillo | 530 cd/m² (Typ.) |
| relación de contraste | 1200:1 (Typ.) |
| mostrar colores | 16.7M (8-bit), CIE193172% |
| tiempo de respuesta | 10/6 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| ángulo de visión | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 20 pcsCCFLEmbedded (Inverter) |
| interfaz de señal | LVDS (1 ch, 8-bit), 41 pins |
| voltaje de entrada | 5.0V (Typ.) |
| solicitud | LCTV |
