| Número de pieza | LS050T1SX06 |
| Marca | SHARP |
| Tamaño | 5.0 |
| Solicitud | MPH |
| Resolución | 1080×1920 |
| Composición | LCM |
| Brillo | 480 |
| CR | 1000:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | WLED |
| Interfaz | MIPI |
| marca de paneles | SHARP |
| modelo de panel | LS050T1SX06 |
| tipo de panel | CG-Silicon , LCM |
| Tamaño del panel | 5.0 inch |
| resolución | 1080(RGB)×1920 , FHD |
| modo de visualización | New Mode2, Normally Black, Transmissive |
| área activa | 61.884×110.016 mm |
| describir | 64.3×116.6×1.5 mm |
| superficie | |
| brillo | 480 cd/m² (Typ.) |
| relación de contraste | 1000:1 (Typ.) |
| mostrar colores | 16.7M (8-bit), CIE193171% |
| tiempo de respuesta | 35 (Max.)(Tr+Td) |
| ángulo de visión | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 6S2PWLEDWithout Driver |
| interfaz de señal | MIPI (4 data lanes), 34 pins |
| voltaje de entrada | 1.8/5.0/-5.0V (Typ.)(IOVDD/VSP/VSN) |
| solicitud | MPH |
