| Número de pieza | LQ043Y1DX03D |
| Marca | SHARP |
| Tamaño | 4.3 |
| Solicitud | MPH |
| Resolución | 480×800 |
| Composición | LCM |
| Brillo | 340 |
| CR | 900:1 |
| Colores | 65K |
| Iluminar desde el fondo | WLED |
| Interfaz | TTL |
| marca de paneles | SHARP |
| modelo de panel | LQ043Y1DX03D |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 4.3 inch |
| resolución | 480(RGB)×800 , WVGA |
| modo de visualización | ASV, Normally Black, Transmissive |
| área activa | 56.16×93.6 mm |
| describir | 62.46×105.9 mm |
| superficie | Hard coating (3H) |
| brillo | 340 cd/m² (Typ.) |
| relación de contraste | 900:1 (Typ.) |
| mostrar colores | 65K , CIE193172% |
| tiempo de respuesta | 35 (Max.)(Tr+Td) |
| ángulo de visión | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 8S1PWLEDWithout Driver |
| interfaz de señal | Parallel RGB, 45 pins |
| voltaje de entrada | 3.3/2.6V (Typ.)(VCI/VDDIO) |
| solicitud | MPH |
| H429AL02.0 | AUO | 4.3 | 540×960 |
| LB043WQ3-TD01 | LG Display | 4.3 | 480×272 |
| LMS430HF02 | Samsung | 4.3 | 480×272 |
| LQ043T1LX01A | SHARP | 4.3 | 540×960 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| LQ043Y1DX01 | SHARP | 4.3 | 480×800 |
| LQ043Y1DX01B | SHARP | 4.3 | 480×800 |
| LQ043Y1DX01D | SHARP | 4.3 | 480×800 |
| LQ043Y1DX02 | SHARP | 4.3 | 480×800 |
| LQ043Y1DX03D | SHARP | 4.3 | 480×800 |
| AMS320FS03 | Samsung | 3.2 | 320×480 |
| BT055FWM-N00 | BOE | 5.5 | 480×854 |
| H650DAN01.0 | AUO | 6.4 | 1080×1920 |
| LH350H01-FD01 | LG Display | 3.5 | 320×480 |
| LH400WV3-SD02 | LG Display | 4.0 | 480×800 |
| LH500WF3-SH01 | LG Display | 5.0 | 1080×1920 |
| LMS241GF31 | Samsung | 2.4 | 240×320 |
| TM020GDH42 | Tianma | 2.0 | 176×220 |
| TM022HDHT1-05 | Tianma | 2.2 | 240×320 |
| TM047XDZP02 | Tianma | 4.7 | 540×960 |
