| Número de pieza | LQ035JC211 |
| Marca | Innolux |
| Tamaño | 3.5 |
| Solicitud | DSC |
| Resolución | 320×240 |
| Composición | LCM |
| Brillo | |
| CR | 400:1 |
| Colores | |
| Iluminar desde el fondo | |
| Interfaz | |
| marca de paneles | ChiHsin |
| modelo de panel | LQ035JC211 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 3.5 inch |
| resolución | 320(RGB)×240 , QVGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 70.08×52.56 mm |
| describir | 76.9×63.9 mm |
| superficie | |
| brillo | |
| relación de contraste | 400:1 (Typ.) |
| mostrar colores | , CIE193160% |
| tiempo de respuesta | 10/15 (Typ.)(Tr/Td) |
| ángulo de visión | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lámpara | |
| rohs: | |
| solicitud | DSC |
