| Número de pieza | LP154WE2-TLA7 |
| Marca | LG Display |
| Tamaño | 15.4 |
| Solicitud | NBPC |
| Resolución | 1680×1050 |
| Composición | LCM |
| Brillo | 200 |
| CR | 500:1 |
| Colores | 262K |
| Iluminar desde el fondo | CCFL |
| Interfaz | LVDS |
| marca de paneles | LG.Philips LCD |
| modelo de panel | LP154WE2-TLA7 9 Compatible model |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 15.4 inch |
| resolución | 1680(RGB)×1050 , WSXGA+ |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 331.38×207.11 mm |
| describir | 344×222×6.5 mm |
| estilo de forma | Wedge (PCBA Bent, Depth ≥5.2mm) |
| superficie | Antiglare (Haze 44%) |
| brillo | 200 cd/m² (Typ.) |
| relación de contraste | 500:1 (Typ.) |
| mostrar colores | 262K (6-bit), CIE193145% |
| tiempo de respuesta | 16 (Typ.)(Tr+Td) |
| ángulo de visión | 65/65/55/55 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 1 pcsCCFLWithout Driver |
| interfaz de señal | LVDS (2 ch, 6-bit), 30 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | NBPC |
