| Número de pieza | LD420WUN-SCA1 |
| Marca | LG Display |
| Tamaño | 42 |
| Solicitud | PID |
| Resolución | 1920×1080 |
| Composición | LCM |
| Brillo | 500 |
| CR | 1300:1 |
| Colores | 16.7M/1.06B |
| Iluminar desde el fondo | EEFL |
| Interfaz | LVDS |
| marca de paneles | LG Display |
| modelo de panel | LD420WUN-SCA1 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 42 inch |
| resolución | 1920(RGB)×1080 , FHD |
| modo de visualización | S-IPS, Normally Black, Transmissive |
| área activa | 930.24×523.26 mm |
| describir | 983×576 mm |
| superficie | Antiglare (Haze 10%), Hard coating (3H) |
| brillo | 500 cd/m² (Typ.) |
| relación de contraste | 1300:1 (Typ.) |
| mostrar colores | 16.7M/1.06B (8-bit / 8-bit + Dithering), CIE193172% |
| tiempo de respuesta | 10 (Typ.)(G to G) |
| ángulo de visión | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | EEFLEmbedded (Inverter) |
| interfaz de señal | LVDS (2 ch, 8/10-bit), 51 pins |
| voltaje de entrada | 12.0V (Typ.) |
| solicitud | PID |
