| Número de pieza | LB048WV1-TL01 |
| Marca | LG Display |
| Tamaño | 4.8 |
| Solicitud | UMPC |
| Resolución | 800×480 |
| Composición | LCM |
| Brillo | 280 |
| CR | 350:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | LG.Philips LCD |
| modelo de panel | LB048WV1-TL01 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 4.8 inch |
| resolución | 800(RGB)×480 , WVGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 103.8×62.28 mm |
| describir | 114.65×74.7×5.88 mm |
| superficie | Glare (Haze 0%), Hard coating (3H) |
| brillo | 280 cd/m² (Typ.) |
| relación de contraste | 350:1 (Typ.) |
| mostrar colores | 262K (6-bit) |
| tiempo de respuesta | 16 (Typ.)(Tr+Td) |
| ángulo de visión | 65/65/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 6S2PWLEDEmbedded (LED Driver) |
| interfaz de señal | LVDS (1 ch, 6-bit), 30 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | UMPC |
