| Número de pieza | LA123WF4-SR03 |
| Marca | LG Display |
| Tamaño | 12.3 |
| Solicitud | Automotive Display |
| Resolución | 1920×720 |
| Composición | a-Si TFT-LCD, LCM |
| Brillo | |
| CR | 800:1 |
| Colores | 16.7M |
| Iluminar desde el fondo | WLED |
| Interfaz | RSDS |
| marca | LG Display |
| modelo | LA123WF4-SR03 |
| tamaño diagonal | 12.3 inch |
| tipo | a-Si TFT-LCD, LCM |
| formato de píxel | 1920(RGB)×720 167PPI |
| configuración | RGB Vertical Stripe |
| área activa | 292.032(H)×109.512(V) mm |
| contorno tenue | 310(H)×128(V) ×10.75(D) mm |
| área del bisel | 296.03(H)×113.5(V) mm |
| tratamiento | Hard coating |
| luminancia | 600 cd/m² (Min.) |
| relación de contraste | 800:1 (Min.) (TM) |
| ver dirección | Symmetry |
| tiempo de respuesta | 30 (Max.)(G to G); 25 (Typ.)(MPRT) |
| ángulo de visión | 89/89/89/89 (Min.)(CR≥10) |
| modo operativo | IPS, Normally Black, Transmissive |
| color de soporte | 16.7M 77% NTSC |
| fuente de luz | WLED [11S4P] , 10K hours , W/O Driver |
| peso | 385/400g (Typ./Max.) |
| diseñado para | Automotive Display |
| cuadros por segundo | 60Hz |
| panel táctil | Without |
| Tipo de interfaz | RSDS (2 Channel) , 110 pins FPC |
| fuente de alimentación | 3.3/13.0V (Typ.)(VCC/VDD) |
| ambiente | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
