| Número de pieza | L5S30883P00 |
| Marca | SANYO |
| Tamaño | 4.5 |
| Solicitud | CNS |
| Resolución | 480×240 |
| Composición | LCM |
| Brillo | 400 |
| CR | 300:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | TTL |
| marca de paneles | SANYO |
| modelo de panel | L5S30883P00 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 4.5 inch |
| resolución | 480(RGB)×240 , WQVGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 99.36×56.04 mm |
| describir | 112.7×70.2 mm |
| superficie | Glare (Haze 0%) |
| brillo | 400 cd/m² (Typ.) |
| relación de contraste | 300:1 (Typ.) |
| mostrar colores | 262K (6-bit) |
| tiempo de respuesta | 10/20 (Typ.)(Tr/Td) |
| ángulo de visión | 55/55/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDEmbedded (LED Driver) |
| interfaz de señal | Parallel RGB (1 ch, 6-bit), 40 pins |
| voltaje de entrada | 3.3V (Typ.) |
| rohs: | |
| solicitud | CNS |
