| Número de pieza | HX121WX1-101 |
| Marca | HYDIS |
| Tamaño | 12.1 |
| Solicitud | NBPC |
| Resolución | 1280×800 |
| Composición | LCM |
| Brillo | 300 |
| CR | 700:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | HYDIS |
| modelo de panel | HX121WX1-101 1 Compatible model |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 12.1 inch |
| resolución | 1280(RGB)×800 , WXGA |
| modo de visualización | AFFS, Normally Black, Transmissive |
| área activa | 261.12×163.2 mm |
| describir | 276.8×180×6.8 mm |
| superficie | Antiglare, Hard coating (2H) |
| brillo | 300 cd/m² (Typ.) |
| relación de contraste | 700:1 (Typ.) |
| mostrar colores | 262K (6-bit), CIE193142% |
| tiempo de respuesta | 30 (Typ.)(Tr+Td) |
| ángulo de visión | 90/90/90/90 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | 12S4PWLEDEmbedded (LED Driver) |
| interfaz de señal | LVDS (1 ch, 6-bit), 40 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | NBPC |
| B121EW01 V0 | AUO | 12.1 | 1280×800 |
| HT12X21-220 | HYDIS | 12.1 | 1024×768 |
| HX121WX1-100 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-101 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-103 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-110 | HYDIS | 12.1 | 1280×800 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LP121X1-A2M1 | LG Display | 12.1 | 1024×768 |
| LT121DKXBF00 | TOSHIBA | 12.1 | 1280×800 |
| LTD121C31S | TOSHIBA | 12.1 | 800×600 |
| B140HAT02.0 | AUO | 14.0 | 1920×1080 |
| L141X1-1 | AUO | 14.1 | 1024×768 |
| LP140WH1-TLE3 | LG Display | 14.0 | 1366×768 |
| LP156WH2-TLAA | LG Display | 15.6 | 1366×768 |
| LP173WF1-TLA1 | LG Display | 17.3 | 1920×1080 |
| LTD121EDFN | TOSHIBA | 12.1 | 1024×768 |
| LTN121AP03-002 | Samsung | 12.1 | 1280×800 |
| LTN154X9-L02 | Samsung | 15.4 | 1280×800 |
| N133BGE-L31 | Innolux | 13.3 | 1366×768 |
| N156BGE-L31 | Innolux | 15.6 | 1366×768 |
