| Número de pieza | HSD140PNW1-B00 |
| Marca | HannStar |
| Tamaño | 14.0 |
| Solicitud | NBPC |
| Resolución | 1600×900 |
| Composición | LCM |
| Brillo | 250 |
| CR | 300:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | eDP |
| marca de paneles | HannStar |
| modelo de panel | HSD140PNW1-B00 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 14.0 inch |
| resolución | 1600(RGB)×900 , HD+ |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 309.6×174.15 mm |
| describir | 320.4×205.1×3 mm |
| estilo de forma | Slim (PCBA Flat, Depth ≤3.2mm) |
| superficie | Antiglare, Hard coating (3H) |
| brillo | 250 cd/m² (Typ.) |
| relación de contraste | 300:1 (Typ.) |
| mostrar colores | 262K (6-bit), CIE193160% |
| tiempo de respuesta | 4/12 (Typ.)(Tr/Td) |
| ángulo de visión | 40/40/15/30 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDEmbedded (LED Driver) |
| interfaz de señal | eDP (2 Lanes), 30 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | NBPC |
