| Número de pieza | H027QT01 |
| Marca | AUO |
| Tamaño | 2.7 |
| Solicitud | MPH |
| Resolución | 208×320 |
| Composición | LCM |
| Brillo | 60 |
| CR | 50:1 |
| Colores | 262K |
| Iluminar desde el fondo | WLED |
| Interfaz | TTL |
| marca de paneles | AU Optronics |
| modelo de panel | H027QT01 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 2.7 inch |
| resolución | 208(RGB)×320 |
| modo de visualización | TN, Normally White, Transflective |
| área activa | 36.816×56.64 mm |
| describir | 45.8×69.17 mm |
| superficie | |
| brillo | 60 cd/m² (Typ.) |
| relación de contraste | 50:1 (Typ.)(Transmissive)20:1 (Typ.)(Reflective) |
| mostrar colores | 262K (6-bit) |
| tiempo de respuesta | 10/30 (Typ.)(Tr/Td) |
| ángulo de visión | 45/45/45/45 (Typ.)(CR≥10)(L/R/U/D) |
| tipo de lámpara | 2S2PWLEDWithout Driver |
| interfaz de señal | Parallel RGB (1 ch, 6-bit), 60 pins |
| voltaje de entrada | 3.3/5/5/3.3/12/-12V (Typ.)(DVCC/AVDD/AVDD1/AVDD2/VGH/VGL) |
| solicitud | MPH |
