| Número de pieza | G156XW01 V1 |
| Marca | AUO |
| Tamaño | 15.6 |
| Solicitud | IA |
| Resolución | 1366×768 |
| Composición | LCM |
| Brillo | 400 |
| CR | 500:1 |
| Colores | 16.2M |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | AUO |
| modelo de panel | G156XW01 V1 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 15.6 inch |
| resolución | 1366(RGB)×768 , WXGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 344.232×193.536 mm |
| describir | 363.8×215.9×17.35 mm |
| superficie | Antiglare, Hard coating (3H) |
| brillo | 400 cd/m² (Typ.) |
| relación de contraste | 500:1 (Typ.) |
| mostrar colores | 16.2M (6-bit + FRC), CIE193170% |
| tiempo de respuesta | 6/2 (Typ.)(Tr/Td) |
| ángulo de visión | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDEmbedded (LED Driver) |
| interfaz de señal | LVDS (1 ch, 8-bit), 30 pins |
| voltaje de entrada | 5.0V (Typ.) |
| solicitud | IA |
