| Número de pieza | G150XGE-L04 Rev.C4 |
| Marca | Innolux |
| Tamaño | 15.0 |
| Solicitud | IA |
| Resolución | 1024×768 |
| Composición | LCM |
| Brillo | 400 |
| CR | 700:1 |
| Colores | 262K/16.2M |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | INNOLUX |
| modelo de panel | G150XGE-L04 Rev.C4 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 15.0 inch |
| resolución | 1024(RGB)×768 , XGA |
| modo de visualización | TN, Normally White, Transmissive |
| área activa | 304.128×228.096 mm |
| describir | 326.5×253.5×12 mm |
| superficie | Antiglare (Haze 25%), Hard coating (3H) |
| brillo | 400 cd/m² (Typ.) |
| relación de contraste | 700:1 (Typ.) |
| mostrar colores | 262K/16.2M (6-bit / 6-bit + FRC), CIE193155% |
| tiempo de respuesta | 5/11 (Typ.)(Tr/Td) |
| ángulo de visión | 80/80/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDEmbedded (LED Driver) |
| interfaz de señal | LVDS (1 ch, 6/8-bit), 20 pins |
| voltaje de entrada | 3.3V (Typ.) |
| solicitud | IA |
