| Número de pieza | G121AGE-L03 |
| Marca | Innolux |
| Tamaño | 12.1 |
| Solicitud | IA |
| Resolución | 800×600 |
| Composición | LCM |
| Brillo | 450 |
| CR | 1500:1 |
| Colores | 262K/16.2M |
| Iluminar desde el fondo | WLED |
| Interfaz | LVDS |
| marca de paneles | INNOLUX |
| modelo de panel | G121AGE-L03 |
| tipo de panel | a-Si TFT-LCD , LCM |
| Tamaño del panel | 12.1 inch |
| resolución | 800(RGB)×600 , SVGA |
| modo de visualización | Super MVA, Normally Black, Transmissive |
| área activa | 246×184.5 mm |
| describir | 260.5×204×8.9 mm |
| superficie | Antiglare, Hard coating (3H) |
| brillo | 450 cd/m² (Typ.) |
| relación de contraste | 1500:1 (Typ.) |
| mostrar colores | 262K/16.2M (6-bit / 6-bit + FRC), CIE193150% |
| tiempo de respuesta | 13/12 (Typ.)(Tr/Td) |
| ángulo de visión | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frecuencia | 60Hz |
| tipo de lámpara | WLEDEmbedded (LED Driver) |
| interfaz de señal | LVDS (1 ch, 6/8-bit), 20 pins |
| voltaje de entrada | 3.3/5.0V (Typ.)(VCC) |
| solicitud | IA |
